High‑Capacity Flat Lifting Slings – Type C, 4
Catégorie : Flat webbing slings
High‑capacity flat slings (up to 40 t), Type C with 4 plies and reinforced eyes. EN 1492‑1+A1 compliant, suitable for heavy loads and demanding environments.
Description
Features
Download
Description
About this product
Designed for heavy‑duty lifting operations, these flat slings offer capacities up to 40 tonnes. Manufactured according to EN 1492‑1+A1, they are ideal for demanding environments such as marine applications, shipyards, industrial sites, and airport operations.
The Type C flat sling features 4 load‑bearing plies and belongs to Category 2, equipped with folded and reinforced eyes to provide enhanced durability.
When lifting around sharp edges, appropriate protective sleeves (PVC, leather, polyurethane, etc.) must be used to protect textile fibers, in compliance with EN 1492‑1+A1.
Alternative eye reinforcement materials are available upon request.
Features
Features
| Product code | SPC2 |
| Material | 100% high tenacity multifilament polyester |
| Standard | EN 1492-1+A1 |
| CMU mini (T) | 0,5 |
| CMU maxi (T) | 40 |
| Usage factor | 7:1 |
| Maximum working length (m) | 50 |
| Operating temperature | From - 40°C up to + 100°C |
| Colour | According to WLL: 6 T brown, 8 T blue, 10 T and more orange… |
| Important information | Informations importantes |
| Référence Produits cross selling | ED12,PP12,SPB2,SPC4,SPC6 |
| Minimum working length (m) | 3 |
| Minimum webbing width (mm) | 30 |
| Maximum webbing width (mm) | 580 |
| Thickness (mm) | 12 to 15 |
| Configuration | C-type: 4 plies |
| Category | Reinforced folded eyes (cat. 2) |
| Weight at 3 m (kg) | From 1,10 up to 19,8 |
| Weight per linear metre (kg) | From 0,40 up to 6,6 |
| Référence Configuration produits similaires | SPB2 |
Download
Range benefits
Traceability guaranteed via the traceability label.
Standard protection for folded loops: textile reinforcement.
100% high-tenacity multifilament polyester (webbing + sewing thread).
Polyester offers high resistance to friction, abrasion, UV rays, and chemicals.
Important information
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
