ROUNDSLING DOUBLE SLEEVE AND MIDDLE STITCH - ECM
Catégorie : Round slings
The sling uses a round sling sleeve, but with a different manufacturing process: the load-bearing core is not inserted inside the sleeve. Instead, it is placed onto the sleeve, which is then folded over and closed around the core.
This range is particularly suitable and recommended for lifting steel structures, as well as for demanding lifting operations.
About this product
Designed for heavy and very high-capacity lifting, the double-sleeve roundsling with side seam meets the requirements of the most demanding sectors, including heavy industry, construction, shipyards and maritime activities.
Its load-bearing core, made from high-tenacity multifilament polyester yarns, is positioned on the textile sleeve. The sleeve is then folded over and sewn along the side to create a double protective layer. This construction provides enhanced protection for the load-bearing fibres and gives the sling a rounder, more regular and uniform shape.
The roundsling with side seam can be manufactured in particularly high capacities and long lengths. Available with a WLL ranging from 1 to 600 tonnes and a usable length of up to 60 metres (please contact us), it is suitable for both exceptional lifting operations and handling applications requiring a short sling or limited clearance.
Each sling is fitted with a label ensuring its identification and traceability. Slings with a capacity of 100 tonnes or more feature two traceability labels: one standard label and a second polyurethane-coated label incorporated as a ring around the sling.
Made from high-tenacity polyester and compliant with the EN 1492-2+A1 standard, with a 7:1 safety factor, the double-sleeve roundsling with side seam is a robust, reliable and durable solution for the most demanding lifting operations.
Features
| Product code | ECM |
| Material | 100% high tenacity multifilament polyester |
| Standard | EN 1492-2+A1 |
| CMU mini (T) | 1 |
| CMU maxi (T) | 10 |
| Coefficient d'utilisation | 7:1 |
| Longueur utile maxi (m) | 80 |
| Poids m/utile (kg) | From 0,37 up to 1,90 |
| Température d'utilisation | From - 40°C up to + 100°C |
| Couleur | According to WLL: 1 T purple, 2 T green, 3 T yellow, 5 T red… |
| Informations importantes | Informations importantes |
| Référence Produits cross selling | ECC,COBRA,PP12,MEGA |
| Longueur utile mini (m) | 0,2 |
| Diamètre d'un brin mini (mm) | 20 |
| Diamètre d'un brin maxi (mm) | 48 |
Range benefits
- Very high capacities: WLL from 1 to 600 tonnes.
- Long lengths available: effective length up to 60 metres (please contact us).
- High-tenacity load-bearing core: made from continuous polyester yarns.
- Double-layer textile cover: open textile cover folded around the core and closed with a central seam.
- Reinforced core protection: enhanced resistance to abrasion, friction and external damage.
- Central longitudinal seam: uniform closure of the cover along the entire length of the sling.
- Polyester construction: load-bearing core, cover and sewing threads.
- Guaranteed traceability: identification label fitted to each sling.
- Double traceability from 100 tonnes: second label protected by a polyurethane coating.
- Wide range of applications: particularly suitable for sectors such as heavy industry, construction, shipbuilding and the maritime industry.
- Complies with EN 1492-2+A1: safety factor of 7:1.
Important information
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
