TENSIONING STRAP BUCKLE 803 - COVERING LC 250 daN
Catégorie : 25 mm webbing leisure activities lashing
These tensioning strap buckle systems are intended for use on light-duty vehicles, for leisure activities or tourism. They have a covering LC of 250 daN – 1,2 T (breaking strength of the webbing only 1,2 T or 1 200 daN) and a STF of 13 daN. The 803 buckle operates with a 25 mm wide webbing.
About this product
Regular product: effective working length 5 m, blue webbing. Additional meter weight: 25 g. Internal range ref: 2A. Customized manufacturing possible: mm specific length, marking and color of the webbing, identical or different fittings… This range is available with: - A ratchet (ref. 909 WH, internal range ref: 2D), - A ratchet with filled handle (ref. 906, internal range ref: 2B). Depending on your use, a wide range of protections is available: polyurethane or PVC sleeve, polyurethane protection keeper, etc.
Features
| Product code | 803 / 2A |
| Material | 100% high tenacity multifilament polyester webbing, steel tensioning buckle |
| Standard | EN 12195-2 |
| Ends / Terminations | Similar or mixed, many possibilites available |
| Useful length (m) | 5 |
| Strap width (mm) | 25 |
| LC en direct (daN) | 125 |
| Double load capacity (daN) | 250 |
| STF (daN) | 13 |
| Breakage of the strap only (T) | 1,2 |
| Length of short section (m) | 0,3 |
Important information
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
