Catégorie : 25 mm webbing leisure activities lashing
These lashing systems are intended for use on light-duty vehicles, for leisure activities or tourism. They have a covering LC of 800 daN – 1,2 T (breaking strength of the webbing only 1,2 T or 1 200 daN) and a STF of 40 daN. The 909 WH ratchet operates with a 25 mm wide webbing and is composed of a gear wheel and a handle, tensioning the webbing by wrapping it around its axis.
About this product
Regular product: effective working length 5 m, blue webbing. Additional meter weight: 25 g. Internal range ref: 2D. Customized manufacturing possible: mm specific length, marking and color of the webbing, identical or different fittings… This range is available with: - A black painted ratchet (ref. 909 WH NO), - A ratchet with filled handle (ref. 906, internal range ref: 2B), - A tensioning strap buckle with a covering LC of 250 daN (ref. 803, internal range ref: 2A). Depending on your use, a wide range of protections is available: polyurethane or PVC sleeve, polyurethane protection keeper, etc.Features
| Product code | 909WH |
| Material | 100% high tenacity multifilament polyester webbing, steel ratchet |
| Standard | EN 12195-2 |
| Ends / Terminations | Similar or mixed, many possibilites available |
| Useful length (m) | 5 |
| Strap width (mm) | 25 |
| LC in straight pull (daN) | 400 |
| Double load capacity (daN) | 800 |
| STF (daN) | 40 |
| Breakage of the strap only (T) | 1,2 |
| Length of short section (m) | 0,3 |
| Operating temperature | From - 40°C up to + 100°C |
| Important information | Informations importantes |
| Sections 0 - Titre section 0 | 2 parts configuration |
| Sections 0 - Terminaison 0 - Image terminaison 0 | https://pms-ind.com/img/p/3/3/2/0/3320.jpg |
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
