These 1-leg slings are manufactured from a galvanized wire cable in accordance with standard EN 13414-1+A2. They have two bare eyes with aluminium ferrule.
SLING WITH PU RINGS AND BARE EYES WITH ALUMINIUM FERRULE - ECA016A
Catégorie : 1 leg slings
These 1-leg slings are manufactured from a galvanized wire cable with PU rings in accordance with standard EN 13414-1+A2. They have two bare eyes with aluminium ferrule.
Description
Features
Download
Description
About this product
Be careful, according to standard EN 13414-1+A2, make sure to always protect your slings if used in a lifting configuration with sharp angles. Consult us for more information and capacities or for any project study.Features
Features
| Product code | ECA016A |
| Material | Galvanized steel |
| Standard | EN13414-1+A2 |
| Ends / Terminations | 2 bare eyes with aluminium ferrule |
| Usage factor | 5:1 |
| Operating temperature | From - 40 °C up to + 100 °C for fiber core, from - 40 °C up to + 150 °C for metallic core |
| Important information | Informations importantes |
| Référence Produits cross selling | ECA017A,ECA015A,ECA004A,ECA001 |
| Minimum working length (m) | Depending on diameter, 2 to 3 |
| Number of legs | 1 |
| CMU facteur M = 1 (kg) | 1 050 to 11 000 |
| Minimum strand diameter (mm) | 10 |
| Maximum strand diameter (mm) | 32 |
| CMU facteur M = 2 (kg) | 2 100 to 22 000 |
| Tensile strength grade (N/mm²) | 1770 |
| Options | Eyes with hoop thimble, regular or reinforced thimble |
Download
Important information
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
