SPLICED BARE EYES SLING - ECA003A
Catégorie : 1 leg slings
These 1-leg slings are manufactured from a galvanized wire cable in accordance with standard EN 13414-1+A2. They have two spliced bare eyes.
Description
Features
Download
Description
About this product
If necessary, we can increase the length of the splice and therefore the number of passes. The WLL is established on the basis of a textile core. You can have a metal core to reach higher capacities. Be careful, according to standard EN 13414-1+A2, make sure to always protect your slings if used in a lifting configuration with sharp angles. Consult us for more information and capacities or for any project study.Features
Features
| Product code | ECA003A |
| Material | Galvanized steel |
| Standard | EN13414-1+A2 |
| Ends / Terminations | 2 bare spliced eyes |
| Coefficient d'utilisation | 5:1 |
| Température d'utilisation | From - 40 °C up to + 100 °C for fiber core, from - 40 °C up to + 150 °C for metallic core |
| Informations importantes | Informations importantes |
| Référence Produits cross selling | ECA001,ECA002,ECA017A,ECA014A |
| Longueur utile mini (m) | Depending on diameter, 2 to 4 |
| Nombre de brin(s) | 1 |
| CMU facteur M = 1 (kg) | 600 to 12 340 |
| Diamètre d'un brin mini (mm) | 8 |
| Diamètre d'un brin maxi (mm) | 36 |
| CMU facteur M = 2 (kg) | 1 200 to 24 680 |
| CMU facteur M = 0,8 (kg) | 480 to 9 872 |
| Type de câble | Galvanized, textile core |
| Classe de résistance (N/mm²) | 1770 |
| Options | Metallic core, eyes with thimble |
Download
Important information
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
