FLEMISH EYE" BARE LOOP SLING - ECA006A
Catégorie : 1 leg slings
These 1-strand rope slings have bare loops with steel sleeves, shaped by mechanical splicing also known as Flemish eye.
Description
Features
Download
Description
About this product
The WLL is established on the basis of a textile core. You can have a metal core to reach higher capacities. Contact us for more information and capacities or for any project study.Features
Features
| Product code | ECA006A |
| Material | Galvanized steel |
| Ends / Terminations | 2 stainless steel bared buckles with Flemish eye |
| Usage factor | 5:1 |
| Operating temperature | From - 40 °C up to + 100 °C for fiber core, from - 40 °C up to + 150 °C for metallic core |
| Important information | Informations importantes |
| Référence Produits cross selling | ECA001,ECA002,ECA003A,ECA016A |
| Minimum working length (m) | Depending on diameter, 2 to 3 |
| Number of legs | 1 |
| CMU facteur M = 1 (kg) | From 700 to 14,000 |
| Minimum strand diameter (mm) | 8 |
| Maximum strand diameter (mm) | 36 |
| CMU facteur M = 2 (kg) | From 1,400 to 28,000 |
| CMU facteur M = 0,8 (kg) | From 550 to 11,250 |
| Wire rope type | Galvanized, textile core |
| Tensile strength grade (N/mm²) | 1770 |
| Options | Metal core, ribbed loops, bright steel |
Download
Important information
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
