Catégorie : 35 mm webbing small business lashing
These tensioning strap buckle systems are intended for use on light commercial vehicles, for small businesses. They have a covering LC of 800 daN – 3,2 T (breaking strength of the webbing only 3,2 T or 3 200 daN) and a STF of 40 daN. The 804 buckle operates with a 35 mm wide webbing.
About this product
Regular product: effective working length 5 m, blue webbing. Additional meter weight: 80 g. Internal range ref: 3C. Customized manufacturing possible: mm specific length, marking and color of the webbing, identical or different fittings… This range is available with a ratchet with secured opening 917 (internal range ref: 3A) or 908 (internal range ref: 3B). A wide range of protections are available depending on your use: polyurethane or PVC sleeves, polyurethane protection keepers, etc.
Features
| Product code | 804 |
| Standard | EN 12195-2 |
| Useful length (m) | 5 |
| Strap width (mm) | 35 |
| Breakage of the strap only (T) | 3,2 |
| Length of short section (m) | 0,3 |
| Operating temperature | From - 40°C up to + 100°C |
| Important information | Informations importantes |
Your safety depends on the correct use of the product. Please refer to the user manual supplied with the equipment.
We have several suppliers; the dimensions are provided for guidance only.
We are able to test all our products up to their maximum capacity by conducting fatigue and load
tests on our test benches.
